Transmitter HyPro
®
-6 7,2V / HyPro
®
-8 7,2 V
Push buttons to enter and store min and max values for valves could differ from the description
above. In this case a separate supplemental information sheet will be attached to the operating
instructions.
Technical data
Transmitter
HyPro-6, HyPro-8
Transmission frequency range See nameplate
Data security Addressing each transmitter using a unique Binary bit code combination
LF-modulation GFSK
Data repetition rate Approx. 15 ms/60 ms
Baud rate 1,200 / 9,600 baud (bit/sec.)
Range Up to 100 m (depending on environment)
Operating voltage Battery 7.2 V NBB
Current consumption Approx. 30 mA – 100 mA (according to technical execution)
RF output < 10 mW ERP
Protection class IP 65
Operating ambient temperature – 20 to + 70 °C
Weight (without battery)
HyPro-6: 1,290 g
HyPro-8: 1,350 g
Measurements (L x W x H) 280 x 160 x 141 mm
If “Joy Teach” does not appear in the display, please switch off the transmitter and
start teach mode activation from the beginning!
