Standard
Vacuum motor 600w
Rotary valve motor 20w
Hose diameter 50mm
Max ceiling height 2,5m
Max. Transport range with
smooth pipes. 15m
Capacity 60kg/time
Noise level: 70dB
Connection VAC / Hz 230/50
Extraction auger motor 60w
Electrical Consumption/ ton 10kW
Max. Wood pellet length 35mm
Max. Wood pellet diameter 8mm
Max. wood pelet fines 1%
2.2 Technical data
EQUIPMENT INPUT / OUTPUT CONNECTION
Supply 230V PE / N / L
Vacuum OUT1 PE / N / L
Extraction Auger OUT2 PE / N / L
Alarm ALARM A / B
Contact Cyclone IN1 1 / 2
Do not use IN2 3 / 4
Distance Sensor DISTANCE Rød / Grøn / Blå
2.3 Print diagram
