1.4 Technical Parameters
Technical item
Details
PON Interface
1 GPON port (Class B+)
Receiving sensitivity: ≤-27dBm
Transmitting optical power: 0~+4dBm
Transmission distance: 20KM
Wavelength
TX: 1310nm, RX: 1490nm
Optical Interface
SC/UPC Connector
(SC/APC Connector for CATV)
LAN Interface
1LAN port for GE and FE automatic adaptive mode and 3FE LAN ports. Full/Half, RJ45
connector
CATV Interface
RF, optical power: +2~-18dBm
Optical reflection loss: ≥45dB
Optical receiving wavelength: 1550±10nm
RF frequency range: 47~1000MHz, RF output impedance: 75Ω
RF output level: 78dBuV AGC range: 0~-15dBm
MER: ≥32dB@-15dBm
Wireless
Compliant with IEEE802.11b/g/n,
Operating frequency: 2.400-2.4835GHz
Support MIMO, Rate up to 300Mbps,
2T2R,2 external antenna 5dBi.
Support: multiple SSID Channel: Auto
Modulation type: DSSS, CCK and OFDM
Encoding scheme: BPSK, QPSK, 16QAM and 64QAM
Push-Button
3, For Functions of Reset, WLAN, WPS
Operating Condition
Temperature: 0℃~+50℃
Humidity: 10%～90%（non-condensing）
Storing Condition
Temperature: -30℃~+60℃
Humidity: 10%~90%（non-condensing）
Power Supply
DC 12V/1A
Power Consumption
≤6W
Dimension
155mm×92mm×34mm（L×W×H）
Net Weight
≤0.24Kg
Table 2: Technical parameters
