English-7
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST
Adjusts the image displayed for non-standard video inputs.
AUTO ADJUST
Automatically adjusts the Image Position, the H. Size and Fine setting.
LEFT/RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN/UP
Controls Vertical Image Position within the display area of the LCD.
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
COLOUR CONTROL SYSTEMS
Five colour presets (9300/7500/sRGB/USER/NATIVE) select the desired colour setting.
The sRGB and NATIVE, colour presets are standard and cannot be changed.
COLOUR RED
Increase or decreases Red. The change will appear on screen.
COLOUR GREEN
Increase or decreases Green. The change will appear on screen.
COLOUR BLUE
Increase or decreases Blue. The change will appear on screen.
TOOL
Selecting TOOL allows you to get into the sub menu.
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSM control settings back to the factory settings. The RESET button
will need to be held down for several seconds to tage effect. Individual settings can be reset by highlighting the
control to be reset and pressing the RESET button.
EXIT
Selecting EXIT allows you exit OSM menu/ sub menu.
LANGUAGE
OSM control menus are available in nine languages.
OSM TURN OFF
The OSM control menu will stay on as long as it is in use. In the OSM Turn OFF submenu, you can select how
long the monitor waits after the last touch of a button to shut off the OSM control menu. The preset choices are
10 - 120 seconds by 5 seconds step.

NEC AccuSync LCD73V Specifications

General

Pixel pitch	0.264 mm
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	55 - 76 Hz
Viewable size diagonal	430 mm
Viewing angle, vertical	140 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	270 cd/m²
Certification	CE; Energy Star; FCC Class B; ISO 13406-2 (Pixel Failure Class II);\\r PCT Gost; TCO03, TÜV ERGONOMIE; TÜV GS; UL/C-UL or CSA; MPR II/ MPR III
Product color	Black, Grey
Cable lock slot	Yes
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB Type-A downstream ports quantity	0
Special features	Rapid Response\\r NaViSet and NaViSet Administrator
Power requirements	100-240V; 50/60Hz
Recommended resolution	1280x1024 @ 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	36 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Bezel width (side)	14 mm
Depth (with stand)	205 mm
Width (with stand)	368 mm
Height (with stand)	381 mm
Weight (with stand)	4000 g
Width (without stand)	- mm
Weight (without stand)	- g
