NEC Display Solutions of America, Inc.
LCD4020-2 Installation Guide
40” LCD Display Rev 1.0
www.necdisplay.com
Display dimensions (cont.)
100mm MOUNTING HOLE PATTERN
Power Switch
AC Inlet
LCD4020-2 Page 4 of 9
