52
Appendix –continued
OSM Lock Out This control completely locks out access to all OSM control functions. When
attempting to activate OSM controls while in the Lock Out mode, a screen will
appear indicating the OSM controls are locked out. To activate the OSM LockOut
function, press "+" key, then SELECT and hold down simultaneously. To de-activate
the OSM Lock Out, press "+" key, then SELECT and hold down simultaneously.
CONTRAST and BRIGHTNESS can be adjusted while in the lock out mode.
OSM Rotation
To switch OSM between Landscape and Portrait modes. Press "+" or "-" to
select.
Resolution Notifier The optimal resolution is 1280 x 1024. If ON is selected, a message will
appear on the screen after 30 seconds, notifying you that the resolution is not
set to 1280 x 1024. Press "+" or "-" to select.
Factory Preset Selecting Factory Preset allows you to reset most OSM control settings back to
the factory settings. Highlighting the control to be reset and pressing the
RESET button can reset individual settings. Press "SELECT" to reset.
Tag8 Sync Threshold Adjusts the slice level of a synchronization signal.
Press "+" or "-" to select.
(Analog input only)
Tag9 Display Mode Provides information about the current display resolution and technical data,
including the preset timing currently being used and the horizontal and
vertical frequencies. Increases or decreases the current resolution. Press
"SELECT" to move the adjustment mode, and press "+" or "-" to adjust.
Monitor Info
Indicates the model and serial numbers of your monitor.
To Next Page
