Specifications
Monitor Specifications MultiSync LCD2090UXi and Notes
SpectraView 2090 Monitor
LCD Module Diagonal: 51 cm/20.1 inches Active matrix; thin film transistor (TFT) liquid
Viewable Image Size: 51 cm/20.1 inches crystal display (LCD); 0.255 mm dot pitch;
Native Resolution (Pixel Count): 1600 x 1200 280 cd/m
2
white luminence; 700:1 contrast ratio,
typical.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7V p-p and Sync Negative 0.3V p-p)
Display Colours 16,777,216 Depends on display card used.
Synchronization Range Horizontal: 31.5 kHz to 91.1 kHz, 99.4 kHz*
2
Automatically
Vertical: 50 Hz to 85 Hz Automatically
Viewing Angle Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
Image Formation Time 16 ms (Typ.) 8 ms (Gray to Gray Typ.)
Resolutions Supported 720 x 400*
1
at 70 Hz to 85 Hz Some systems may not support all modes listed.
640 x 480*
1
at 60 Hz to 85 Hz
800 x 600*
1
at 56 Hz to 85 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
1
at 60 Hz to 85 Hz
1152 x 864*
1
at 70 Hz to 85 Hz
1152 x 870*
1
at 75 Hz
1280 x 960*
1
at 60 Hz
1280 x 1024*
1
at 60 Hz to 85 Hz
1200 x 1600*
1
at 60 Hz NEC DISPLAY SOLUTIONS cites recommended
1600 x 1200 at 60 Hz....................... resolution for optimal display performance.
Active Landscape: Horiz.: 408 mm/16.1 inches
Display Area Vert.: 306 mm/12.0 inches
Portrait: Horiz.: 306 mm/12.0 inches
Vert.: 408 mm/16.1 inches
Power Supply AC 100-240 V ~ 50/60 Hz
Current Rating 0.68 - 0.29 A (with Option)
Dimensions Landscape: 439.2 mm (W) x 415.5 - 565.5 mm (H) x 247.3 mm (D)
17.3 inches (W) x 16.4 - 22.3 inches (H) x 9.7 inches (D)
Portrait: 340 mm (W) x 465.1 - 615.1 mm (H) x 247.3 mm (D)
13.4 inches (W) x 18.3 - 24.2 inches (H) x 9.7 inches (D)
Height Adjustment: 150 mm / 5.9 inches (Landscape)
Weight 9.7 kg (21.4 lbs)
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Humidity: 30% to 80%
Altitude: 0 to 10,000 Feet/0 to 3,048 m
Storage Temperature: -10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet/0 to 12,192 m
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 1200 x 1600 resolution only.
NOTE: Technical specifications are subject to change without notice.
