NEC MultiSync V423 User Manual

(31/72)
Item OP
cod
e
pag
e
OP code Parameter Remarks
H
Position
02h
38h 0: Left
|
MAX.: Right
OSD
Position
V
Position
02h
39h 0: Down
|
MAX.: Up
Information OSD 02h
3Dh 0:Disable information OSD
3-10:
OSD timer [seconds]
OSD Transparency 02h
B8h 0: None
1: Off(Opaque)
2: On(Translucent)
3: (reserved)
OSD Rotation 02h
41h 0: Normal
1: Rotated
Closed Caption 10h
84h 0: No operate
1: Off
2: CC1
3: CC2
4: CC3
5: CC4
6: TT1
7: TT2
8: TT3
9: TT4
Menu tree reset
(OSD)
02h
CBh 0: None
7: Reset
OSD category
Momentary
Monitor ID 02h
3Eh 1-100:ID
Group ID 10h
7Fh 0: No assignment
1: Group A
2: Group B
3: Group AB
4: Group C
5: Group AC
│
1023:Group ABCDEFGHIJ
Bit0:Group A
Bit1:Group B
Bit2:Group C
Bit3:Group D
Bit4:Group E
Bit5:Group F
Bit6:Group G
Bit7:Group H
Bit8:Group I
Bit9:Group J
IR Control 02h
3Fh 1: Normal
2: Primary
3: Secondary
4: Lock (Off)
H monitor 02h
D0h 1
|
10
Number
of H-division
V monitor 02h
D1h 1
|
10
Number
of V-division
Position 02h
D2h 1: Upper left
|
MAX.: Lower right
Tile comp 02h
D5h 1: Disable (Off)
2: Enable (On)
MULTI DISPLAY
Tile
Matrix
Mode 02h
D3h 1: Disable (Off)
and display frame
2: Enable (On)
3: Disable (Off)
and erase frame
(Set only)
