72
6. Appendix
6-6. Specications
6-6-1. Projector
Model name DLP Cinema
®
Projector Head : NP-42HD
Light Module NP-24LU03 NP-20LU03 NP-18LU03
DLP Cinema
®
Projector NP-NC2443ML NP-NC2043ML NP-NC1843ML
Projection method 3 chip DLP Cinema
®
method
0.98-inch DC4K chip
Panel resolution 4096×2160
Light type Laser Diode
Screen sizes
Max. 22 m Max. 20 m Max. 19 m
@14ft-L / Screen Gain 1.8 (Depends on setup conditions)
Contrast ratio 2000:1 with DCI specified color representation
Lens adjustment function Motorized lens shift (vertical/horizontal), motorized zoom, motorized focus, douser
Signal input ports When shipped from factory: Empty (for mounting optional components) (Note 1)
External Control RS-232C (D-sub 9pin) x 1
GPIO port (D-sub 37 pin) x 1
Service terminal (stereo mini jack) x 1
3D CTL (D-sub 15 pin) x 1
USB (Type A) x 1
Interlock port x 1
Ethernet port (G-bit RJ-45) x 1
Power supply voltage
With a C1 connection
(Note 3)
Projector power supply +
Light power supply
Single-phase AC 200V-240V 50/60Hz
With a C2 connection
(Note 3)
Projector power supply Single-phase AC 100V-240V 50/60Hz
Light power supply Single-phase AC 200V-240V 50/60Hz
Input current
With a C1 connection
(Note 3)
Projector power supply +
Light power supply
19.1A
With a C2 connection
(Note 3)
Projector
power supply
for AC 100 V 7.0A
for AC 200 V 3.5A
Light power supply 15.6A
Power consumption
With a C1 connection
(Note 3)
Projector power supply +
Light power supply
3,182W 3,146W
With a C2 connection
(Note 3)
Projector power supply 362W 352W
Light power supply 2,820W 2,794W
Cooling method Air cooling system and liquid cooling system
Noise level 50 dB or less
Installation Orientation: Desk/ front, desk/ rear, ceiling/ front, ceiling/ rear
Net weight 153 kg (total weight of projector and NP-24LU03 or NP-20LU03
light module. Not including the lens.)
144 kg (total weight of projector
and NP-18LU03 light module.
Not including the lens. )
Dimensions 697 mm (width) × 1,095 mm (depth) × 509.5 mm (height)
Environment Operating temperature: 10 to 35°C
Operating humidity: 10 to 85% (non-condensing)
Storage temperature: -10 to 50°C
Storage humidity: 10 to 85% (non-condensing)
Operating altitude: 0 to 3000 m/9800 feet
(Note 1) The video input slots are empty when the device is shipped. Input ports can be added by mounting option boards, which
are sold separately. (See page 78)
(Note 2) The value is typical.
(Note 3) A “C1 connection” is when the AC power is supplied to the projector power supply and the light power supply with a single
power cable.
A “C2 connection” is when the AC power is supplied to the projector power supply and the light power supply by separate
power cables.
* For the standards related to laser products to which this projector conforms, see the section “To ensure safe use of this unit, be
sure to read this before using the unit” (page 2).
* Note that these specifications and design can change without prior notice.
