Compatibility Modes
Signal Resolution (dots)
Aspect
Ratio
Refresh Rate
(Hz)
VGA 640x480 4:3 60/72/75/85
SVGA 800x600 4:3 56/60/72/75/85
XGA 1024x768
(*1)
4:3 60/70/75/85
XGA+ 1152x864 4:3 60/75/85
WXGA
1280x768
(*2)
15:9 60
1280x800
(*2)
16:10 60
1360x768
(*3)
16:9 60
Quad-VGA 1280x960 4:3 60
SXGA 1280x1024 5:4 60
SXGA+ 1400x1050 4:3 60
WXGA+ 1440x900 16:10 60
WXGA++ 1600x900
(*3)
16:9 60
UXGA 1600x1200 4:3 60
HD 1280x720 16:9 60
MAC 13” 640x480 4:3 67
MAC 16” 832x624 4:3 75
MAC 19” 1024x768 4:3 75
MAC 21” 1152x870 4:3 75
Analog RGB

Signal Resolution (dots)
Aspect
Ratio
Refresh Rate
(Hz)
VGA 640x480 4:3 60
SVGA 800x600 4:3 60
XGA 1024x768
(*1)
4:3 60
WXGA
1280x768
(*2)
15:9 60
1280x800
(*2)
16:10 60
1360x768
(*3)
16:9 60
Quad-VGA 1280x960 4:3 60
SXGA 1280x1024 5:4 60
SXGA+ 1400x1050 4:3 60
WXGA+ 1440x900 16:10 60
WXGA++ 1600x900
(*3)
16:9 60
HDTV 1920x1080 16:9 50/60
HDTV(1080i) 1920x1080 16:9 50/60
HDTV(720p) 1280x720 16:9 50/60
SDTV(480p) 720x480 4:3/16:9 60
SDTV(576p) 720x576 4:3/16:9 50
HDMI

(*1)Native resolu-
tion on XGA model
(U300X/U250X).
(*2)Native resolu-
tion on WXGA
model (U310W/
U260W).
(*3) The projector
may fail to display
these signals
correctly when
[AUTO] is selected
for [Aspect Ratio]
in the on-screen
menu. The factory
default is [AUTO]
for [Aspect Ratio].
To display these
signals, select
[16:9] for [Aspect
Ratio].
