Necta Vending Solutions SpA Sfera - Wiring Diagram

© by NECTA VENDING SOLUTIONS SpA 0404 211 - 02
57
INITIALS DESCRIPTION
WIRING DIAGRAM LEGEND
INITIALS DESCRIPTION
BDV BDV COIN MECH CONNECTORS
CF FILTER CONDENSER
CM0-9 VENDING MOTOR CAM
CMV DISPENSING COMPARTMENT MOTOR C
D DIODE
EX EXECUTIVE COIN MECH CONNECTOR
FA RADIO INTERFERENCE SUPPRESS
FD PHOTODIODE
FT PHOTOTRANSISTOR
IP DOOR SWITCH
ISA OPEN DISP COMPT FLAP SWITCH
LCD LIQUID CRYSTAL DISPLAY
M1-... RELEASE MOTOR
MBV DISPENSING COMPARTMENT LOCK MO
MDB CONNECTOR FOR MDB COIN MECHANI
MIP PROGRAMMING ACCESS MICROSWITCH
MS1 DISP COMPT FLAP MICROSWITCH
MUR COMPRESSOR
MVT FAN
NTC TEMPERATURE PROBE
PIP PROGRAMMING BUTTON
R ANTI-CONDENSATION HEATING ELEMEN
RS232 SERIAL PORT
RT BALLAST
SOR OUT/R BOARD
SP PUSH-BUTTON BOARD
ST STARTER
SUC C.P.U. BOARD
TR TRANSFORMER
TX.... DELAYED FUSE (X=COURRENT)
