7
Monthly Cleaning Steps
1
2
3
4
5
6
7
8
1. Canister lid
2. Canister extension (optional)
3. Spring
4. Toothed wheel
5. Worm screw
6. Pin for toothed wheel
7. Soluble canister
8. Canister elbow
2.
4.
Lock all canisters, then remove them
from the machine. Empty them and
disassemble every part.
1.
3.
Unplug the 5 hoses from the mixers,
the hot water funnel and the brew
group then remove them. Take the
hoses spout part out.
Remove the mixer impellers by
pulling on them. Separate all mixers’
components.
Remove all mixers by moving
the canisters’ spouts out of the
way and rotating the ring nuts
counterclockwise.
To Next Page
