ANPR LUMO | QUICK REFERENCE GUIDE
4/6
CONNECTIONS
Ethernet connection
The Ethernet communication cable (Cat5e, 5 meter) is already fitted to the RJ-45 network connector.
Multi-wire cable
Power supply Red
Blue
Black
Power supply +24VDC ~ 1A
Ground 0V
Ground 0V
Rs485 connection Yellow
Green
Purple
RS-485 A
RS-485 B
RS-485/Wiegand GND
Wiegand White
Brown
Wiegand Data-0
Wiegand Data-1
Relay output 1 White/Green
Brown/Green
Relay output 0 (normally open contact, U
max
=
24VDC, I
max
= 2A)
Relay output 0 (common contact)
Relay output 2 White/Yellow
Brown/Yellow
Relay output 1 (normally open contact, U
max
=
24VDC, I
max
= 2A)
Relay output 1 (common contact)
Trigger input 1 Pink
Gray
Digital input IN+ (optocoupler positive contact, U =
5 - 24VDC)
Digital input IN– (optocoupler negative contact)
Trigger input 2 Gray/Pink
Red/Blue
Digital input IN+ (optocoupler positive contact, U =
5 - 24VDC)
Digital input IN– (optocoupler negative contact)
The network cable and the multi-wire cable should be placed parallel to each other.
ASSIGN AN IP-ADDRESS
Enter the default IP-address in the address bar of your web browser.
Default IP address: 192.168.3.15
The login window appears where the user is asked to type the username and password.
Username: admin
Password: secret
Go to the system configuration and setup the network configuration as desired. If required, now also other
configuration settings may be changed.
