Nederman NCF Series User Manual

NCF fan
EN
3.4.3Technical data 60 Hz fans, 380 V (metric)
NCF 30/25 NCF 40/25 NCF 50/25 NCF 80/20 NCF 120/25 NCF 160/25
Capacity [m
3
/
h]
830 - 6000 910 - 6550 800 - 5600 1600 - 8540 2340 - 11650 2650 - 17140
Total pressure
[Pa]
2540 - 870 3640 - 1320 4540 - 1570 3170 - 1020 5260 - 1700 5060 - 1870
Motor power
[kW]
4,0 5,5 5,5 7,5 15 18,5
Speed [r/min] 3535 3510 3520 3550 3550 3560
Voltage [V]
Current [A]
380Δ
8,2
380Δ
10,8
380Δ
10,8
380Δ
14,5
380Δ
27,9
380Δ
34
Phase 3 phase 3 phase 3 phase 3 phase 3 phase 3 phase
Starting cur-
rent
6-7 x rated cur-
rent
6-7 x rated cur-
rent
6-7 x rated cur-
rent
6-7 x rated cur-
rent
6-7 x rated cur-
rent
6-7 x rated current
Protection IP 55 IP 55 IP 55 IP 55 IP 55 IP 55
Weight [kg] 105 110 112 150 232 292
Working tem-
perature [°C]
Max + 60 Max + 60 Max + 60 Max + 60 Max + 60 Max + 60
Ambient tem-
perature [°C]
-30 to +40 -30 to +40 -30 to +40 -30 to +40 -30 to +40 -30 to +40
Sound power
level Lw(A) ±
3dB
*
95dB(A) 97dB(A) 96dB(A) 95dB(A) 101dB(A) 102dB(A)
Sound pres-
sure level
Lp(A) ± 3dB *
82dB(A) 83dB(A) 86dB(A) 83dB(A) 89dB(A) 90dB(A)
*
Reference standards: ISO 3744, ISO 3746, ISO 13347. Installation Type D: ducted inlet, ducted outlet.
