Nederman WeldFilter EC20 - Technical data

69019 02(00)
17
WeldFilter EC10/EC20 EN
4 Technical data
EC10
EC20
Filtration efficiency
≥ 99%*
≥ 99%*
Filter area
12 m
2
2 x 12 m
2
Dimensions
785 x 665 x 1200 mm
785 x 665 x 1450 mm
Weight (approx.)
150 kg**
210 kg**
Maximum airflow
900 m
3
/h***
2x900 m
3
/h***
Compressed air for air cleaning
3-4 bar****
3-4 bar****
Voltage/phase/frequency/ amperage
See type label
See type label
Ambient temperature
max. +40 °C
min. -10 °C
max. +40 °C
min. -10 °C
Fume temperature
max. +60 °C
max. +60 °C
Material recycling
95% per weight*****
95% per weight*****
Noise level
72 dB(A)******
72 dB(A)******
Hose dimension (air gun)
3/8”
3/8”
Application
Welding fume
Welding fume
* For welding fume
** Without extraction arms.
*** Max 1,100 m
3
/h (EC10)/2,200 m
3
/h (EC20) without extraction arms.
**** Dry and without oil.
***** Without filter cartridge.
****** According to ISO 11203.
