nedis DVBT2265BK - DVB-T2 Set Top Box; Intended Use; Parts List; Front;Rear Panel

6
a
Quick start guide
DVB-T2 Set Top Box DVBT2265BK
For more information see the extended manual online:
ned.is/dvbt2265bk
Intended use
•
The Nedis DVB-T2 Set Top Box allows you to view DVB-T Digital Television
broadcasts on your TV and is exclusively meant for this purpose.
• The product is intended for indoor use only.
• Any modication of the product may have consequences for safety, warranty
and proper functioning.
Parts list
Front Panel [see image A]
1
USB port USB ash drive connection (record / play video
les).
2
Sensor Remote control signal receiver.
3
LED display Channel number indicator.
4
Power button Set Top box on/o switch.
5
Change channel button Channel down.
6
Change channel button Channel up.
Rear panel [see Image B]
1
RF IN Aerial cable connection.
2
RF OUT Incoming signal duplicator connection (from RF
IN to another device).
3
LAN Ethernet cable connection (home network).
4
HDMI OUT Digital connection (TV or AV-receiver).
5
SCART OUT Analogue TV connection.
6
DC IN Mains adapter connection.
The terms HDMI and HDMI High-Denition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States and
other countries.
