Quick start guide
HDMI™ Converter VCON3461BK
For more information see the extended manual online:
ned.is/vcon3461bk
Intended use
The VCON3461BK is an HDMI to SCART converter.
The product is intended for indoor use only.
The product is not intended for professional use.
Any modication of the product may have consequences for safety, warranty
and proper functioning.
Specications
Product HDMI™ Converter
Article number VCON3461BK
Dimensions (w x h x d) 58.4 x 25 x 88.5 mm
Weight 50 g
USB power cable output 5 VDC ; 1 A
Max working current 600 mA
HDMI input / output resolution Up to 1.3 / 60 fps
Support HDMI video color
format
24 bit / deep color 30 bit / 36 bit
HDMI max bandwidth 300 MHz
HDMI max baud rate 10.2 Gbps
Input / Output TMDS signal 0.5 ~ 1.5 V p-p (TTL)
Input / Output DDC signal 5 V p-p (TTL)
RCA analog output (1 KHZ @
0 dB )
1 V RMS
Signal-to-noise-ratio @ dB
(CC1R / ARM)
≥ 90 dB
Distortion ≤ 0.1 %
