nedis VREP3460AT - Quick Start Guide; Kurzanleitung

4
a
Quick start guide
HDMI extender VREP3460AT
For more information see the extended manual
online: ned.is/vrep3460at
Intended use
This product is exclusively intended to transfer HDMI signal
between two HDMI cables through an Ethernet cable.
The product is not intended for professional use.
Any modication of the product may have consequences for safety,
warranty and proper functioning.
Main parts (image A)

Sender

Receiver

Power supply

Infrared transmitter (2x)

Infrared receiver (2x)
Safety instructions
-
WARNING
• Only use the product as described in this manual.
• Only use the provided power supply.
• Do not use the product if a part is damaged or defective.
Replace a damaged or defective device immediately.
• Do not immerse the product in water.
• Do not unplug the power supply by pulling on the cable. Always
grasp the plug and pull.
• Do not plug or unplug the power supply with wet hands.
Check the contents of the package
Check that all parts are present and that no damage is visible on
the parts. If parts are missing or damaged, contact the Nedis B.V.
service desk via the website: www.nedis.com.
Connecting the product (image B)
1. See image B for a connection overview.
Specications
Product HDMI extender
Article number VREP3460AT
Dimensions (l x w x h) 97 x 90 x 30 mm
Input transmitter / Output
receiver
HDMI Type A
Output transmitter / Input
receiver
Cat 5e/6, RJ-45
Max. supported video format 4K @ 30 Hz
Other supported video
formats
480i/480p/576i/576p/720p/10
80i/1080p
Supported audio format LPCM ; DTS Digital, Dolby
Digital (incl. DTS-HD and Dolby
True HD)
Max. transfer rate 10.2 Gb/s
Infrared support 20,000 - 60,000 Hz
Operating temperature 0 °C - +40 °C
Operating humidity 5 - 90% (no condensation)
Power supply 12 VDC / 2 A
Declaration of Conformity
We, Nedis B.V. declare as manufacturer that the product
VREP3460AT from our brand Nedis
®
, produced in China, has been
tested according to all relevant CE standards and regulations and
that all tests have been passed successfully. This includes, but is not
limited to the RED 2014/53/EU regulation.
The complete Declaration of Conformity (and the safety datasheet
if applicable) can be found and downloaded via webshop.nedis.
com/VREP3460AT#support
For additional information regarding the compliance, contact the
customer service:
Web: www.nedis.com
E-mail: service@nedis.com
Phone: +31 (0)73-5991055 (during oce hours)
Nedis B.V., de Tweeling 28
5215 MC ’s-Hertogenbosch, the Netherlands
c
Kurzanleitung
HDMI-Extender VREP3460AT
Weitere Informationen nden Sie in
der erweiterten Anleitung online:
ned.is/vrep3460at
Bestimmungsgemäße Verwendung
Dieses Produkt ist exklusiv zur Übertragung eines HDMI-Signals
zwischen zwei HDMI-Kabeln über ein Ethernetkabel gedacht.
Das Produkt ist nicht für den professionellen Einsatz gedacht.
Jegliche Modikation des Produkts kann Folgen für die Sicherheit,
Garantie und ordnungsgemäße Funktionalität haben.
Hauptbestandteile (Abbildung A)

Sender

Empfänger

Stromversorgung

Infrarot-Transmitter (2x)

Infrarot-Empfänger (2x)
Sicherheitshinweise
-
WARNUNG
• Verwenden Sie das Produkt nur wie in dieser Anleitung
beschrieben.
• Verwenden Sie nur das mitgelieferte Netzteil.
• Verwenden Sie das Produkt nicht, wenn ein Teil beschädigt ist
oder es einen Mangel aufweist. Ersetzen Sie ein beschädigtes
oder defektes Gerät unverzüglich.
• Tauchen Sie das Produkt nicht in Wasser.
