nedis VSPL3468AT - Page 5

5
3. Plug A
8
into A
1
.
4. Plug the other end of A
8
into a power outlet.
Using the splitter
1. Press A
7
to switch on the product.
A56 lights up.
2. Press A
7
to switch off the product.
Specications
Product HDMI Splitter
Article number VSPL3468AT
Dimensions (l x w x h) 257 x 120 x 25 mm
Weight 730 g
Video amplier bandwidth 3.4 Gbps / 340 MHz
Vertical frequency range 50 / 60 Hz
Input port 1 x HDMI 19 pin female
Output ports 8 x HDMI 19 pin female
Max. supported video format 4K2K @ 30 Hz with Full 3D
Other supported video formats 1080i / 576i / 480i
1080p / 720p / 576p / 480p
Operating temperature 0 °C - 45 °C
Storage temperature -10 °C - 80 °C
Operating humidity 10 - 85% RH (no condensation)
Storage humidity 5 - 90% RH (no condensation)
Input DDC signal 5 volts p-p (TTL)
Power consumption 8.5 W
Power supply 5 V DC / 3 A
Warranty 1 year
