en Operating the appliance
8
Lighting
The lighting can be switched on and off independently
of the fan.
Touch the 6 symbol.
Setting the brightness
Press and hold the 6 symbol until the required
brightness is reached.
Saturation display
If the metal grease filters or the activated charcoal filter
are/is saturated, the corresponding symbols flashes
after the appliance is switched off:
■ Metal grease filter: ”ª
■ Activated charcoal filter: ’ª
■ Metal grease filter and activated charcoal filter:
ӻ and ջ
If you have not yet done so, the metal grease filters
should now be cleaned or the activated charcoal filter
replaced. ~ "Cleaning and maintenance" on page 9
Note: The saturation indicator does not apply for non-
renewable activated charcoal filters that are inserted
downstream of the metal grease filter. These activated
charcoal filters must be replaced twice a year.
The saturation indicators can be reset while they are
flashing. To do this, touch the ( symbol.
Switching over the display for air circulation mode
For air recirculation mode, the electronic controller must
be switched over accordingly:
■ The extractor hood must be connected and switched
on.
■ Touch and hold the Q symbol and touch
the ( or ) symbol until "2" lights up for air
recirculation mode (filters that cannot be
regenerated). Take your finger off the Q symbol.
This will switch the electronic controller over to air
recirculation mode (filters that cannot be
regenerated).
■ Touch and hold the Q symbol and touch
the ( or ) symbol until "3" lights up for air
recirculation mode (filters that can be regenerated).
Take your finger off the Q symbol. This switches the
electronic controller over to air recirculation mode
(filters that can be regenerated).
■ Repeatedly touching and holding the Q symbol and
touching the ( or ) symbol until "1" lights up switches
the electronic controller back over to air extraction
mode.
Audible signal
Switching on
Touch and hold the # and Q symbols at the same
time for approximately 3 seconds when the fan is
switched off. An audible signal will sound as an
acknowledgement.
When the signal tone is activated, ‚ will be lit.
Switching off
Touch and hold the # and Q symbols at the same
time for approximately 3 seconds when the fan is
switched off. An audible signal will sound as an
acknowledgement.
When the signal tone is deactivated, ‹ will be lit.

NEFF D95BMP5N0 Specifications

General

Current	10 A
Motor power	140 W
Connected load	145 W
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	34 kWh
Noise level	55 dB
Intensive speed	Yes
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	45 dB
Maximum extraction power	702.1 m³/h
Maximum recirculating power	378 m³/h
Minimum distance from gas hob	650 mm
Noise level (intensive speed)	66 dB
Noise level (recirculation mode)	73 dB
Grease filtering efficiency class	B
Minimum distance from electric hob	550 mm
Bulb type	LED
Bulb power	1.5 W
Illuminance	373 lx
Number of bulbs	3 bulb(s)
Lighting position	Front
Grease filter type	Stainless steel
Type	Wall-mounted
Motor type	Brushless motor
Cord length	1.3 m
Control type	Touch
Certification	CE, VDE
Product color	Black, Stainless steel
Exhaust location	Top
Exhaust connection diameter	150 mm

Weight and Dimensions

Depth	500 mm
Width	898 mm
Weight	19363 g
Height (max)	1139 mm
Height (min)	528 mm
Height without chimney	46 mm
