2/8
N 50, I
n
duction hob w
i
th in
t
eg
r
a
t
ed
v
entilation
syste
m, 80 cm
T48CB1AX2
Features
Design
●
Frameless
●
80 cm: space for 4 pots or pans.
Flexibility of cooking zones
●
Cooking zone front left: 210 mm, 2.2 KW (max. power 3.7 KW)
●
Cooking zone rear left: 180 mm, 1.8 KW (max. power 3.1 KW)
●
Cooking zone rear right: 180 mm , 1.8 KW (max power 3.1 KW)
●
Cooking zone front right: 210 mm, 2.2 KW (max. power 3.7 KW)
Usage convenience
●
Touch control: control the power with imprinted +/- touch
buttons.
●
Variable 17-stage power settings for each zone: precisely adapt
the heat with 17 power levels (9 main levels and 8 intermediate
levels).
●
Timer with automatic shut off for all zones
: switches off the cooking zone at the end of the time set (e.g. for
boiled eggs).
●
LED timer for each zone with switch off function and acoustic
signal
: an alarm sounds at the end of the time set (e.g. for pasta).
Time saving & efficiency
●
Power Boost function for all zones
: boil water faster thanks to 50% more energy than at the highest
standard level.
●
QuickStart function: when switching on, the hob automatically
selects the cooking zone with cookware (when placed on a zone
whilst the hob is off).
●
ReStart function: in case of unintentional switch-off, this feature
restores all previous settings by switching on the hob again within
4 seconds.
●
Quick-Off: quickly switch off a cooking zone with one longer
touch.
Safety
●
2 stage residual heat indicators: indicates which cooking zones
are still hot or warm.
●
Control panel lock: prevent unintended activation of the hob.
●
Control panel suspension: wipe overboiled liquids without
unintentionally changing settings (blocking all touch buttons for
30 seconds).
●
Main switch: switch off all cooking zones at the touch of a button.
●
Safety cut out facility: for safety reasons, heating stops after a
preset time if not used (possible to customise).
Installation
●
Dimensions of the product (HxWxD mm): 223 x 802 x 522
●
Required niche size for installation (HxWxD mm) : 223 x 750 x
(490 - 490)
●
Min. worktop thickness: 16 mm
●
Connected load: 7.4 KW
●
4.6kW power output (20A); current management options for
16A, 13A or 10A connection: limit the maximum power if needed
(depends on fuse protection of electric installation).
●
Power cord: 1.1 m, Cable included in packaging
Integrated ventilation downdraft system
●
Induction cooktop with fully integrated high-performance
downdraft extractor.
●
Suitable for ducted or recirculated extraction configuration (incl.
differentiated software modes). Respective mandatory installation
accessories required:
- Z811DU0 for ducted extraction.
- Starter kit Z821UD0 for unducted recirculation with cleanAir
odour filters.
- Z821PD0 for fully ducted and partly-ducted recirculation with
cleanAir odour filters.
●
- Z811DU0 for ducted extraction.
●
- Z821PD0 for fully ducted and partly-ducted recirculation
with cleanAir odour filters. Starter kit Z821UD0 for unducted
recirculation with cleanAir odour filters.
●
Aesthetically integrated fully flush air intake design with floating,
heat resistant glass ceramics element for free movement and
placement of cookware.
●
Ventilation system with 3 electronically controlled fan power levels
and 1 Boost-/Intensive fan power levels (with automatic revert)
via Touch control user interface
●
- Automatic switch-on of ventilation system when a cooking zone
is used.
●
- Automatic delayed shut-off after cooking to erase residual odors
after cooking (in specific ultra low-noise fan level, 12min in ducted
extraction, 30min in recirculated extraction, can be shut-off
manually).
●
- Fully manual control possible via Touch control.
●
High-performance, low-noise motor with energy-efficient
BLDC-technology. High extraction rates at very low noises
with pleasant noise frequencies through psycho-acoustically
and aerodynamically optimised interior with enclosed, hidden
motor. Highly pressure-drop resistant even with longer and more
complex ducting systems.
●
Easy-to-detach and easy-to-clean grease filter and liquid collector
unit:
- Convenient one-hand removal of unit via floating glass ceramics
handle.
- Integrated, large-scale, high performance stainless-steel
grease filters with 12 filtration layers and one black top layer for
