NEFF T48CB1AX2 - Page 5

5/8
N 50, I
n
duction hob w
i
th in
t
eg
r
a
t
ed
v
entilation
syste
m, 80 cm
T48CB1AX2
Features
supported using suitable substructures. The overall appliance
weight and the worktop manufacturer's structural integrity
specifications are to be taken into account.
●
- The "Plug 'n Play" starter kit Z821UD0 for unducted recirculation
enables easy and quick installations and can be planned in all
worktop depths ≥60cm. For ducted installations - in ducted
extraction (Z811DU0) as well as fully or partly ducted recirculation
(Z821PD0) - a worktop depth of ≥70cm is required.
●
- For partly ducted and unducted recirculation extraction
installations, a return-flow aperture of ≥400cm² is to be respected
in the plinth area. The aperture can be realized via outlet grids,
lamella grids or subtly shortened plinths depending on the
assortment of the kitchen furniture manufacturer.
●
- The air outlet on the backside of the appliance can directly be
accessed with a male flat duct element (DN 150).
●
- The pressuredrop resistant blower allows longer and more
complex ductings up to 8m with three 90° bows while keeping
sufficient performance.
●
- When installing a ventilation hood with ducted extraction
and a chimney-vented fireplace, the power supply line of the
appliance needs a suitable safety switch. This is not required for
configurations in recirculated extraction.
●
- In ducted extraction configuration a one-way flap (or backflow
trap) with a maximum opening pressure of 65Pa should be
installed.
