NEO Suspender - Harness Adjustments

Adjustments
The Suspender is fully adjustable to t your morphology and your preferred ight
position. Before starting the adjustments, loosen every webbing adjuster setting to
it’s maximum.
Seat adjustments
First, set all the seat adjustments : these settings allow you to position yourself cor-
rectly in the harness. Sit in the harness and choose your position, set the inclination
and the depth of the seat using the lateral straps. The optimal position is when the
pilots centre of gravity is between the under-seat webbing 1 and 2 (SC1 and SC2).
The position of the centre of gravity has a big inuence on the stability and the ight
component of the Suspender.
.
Inclination : Adjust the lateral straps to sit supine or upright.
Depth of the seat : Tighten the straps to make the harness shallower and raise the
lumbar support.
Shoulder straps : Adjust the shoulder straps as normal, but not too strap will complete
the shoulder strap tension.
Gravity center
