- 13 -
1. Power cord length, if supplied, is 2 meters.
Unit Type
1
Amperage Plug Type
115/60/1 15 NEMA 5-15
115/60/1 20 NEMA 5-20
100/50-60/1 15 NEMA 5-15
100/50-60/1 20 NEMA 5-20
230/50/1 All Country Specific
Installation and Operation
Power Cord Set
230 Volt, 50 Hertz units do not come with a power cord set. To select the
proper power cord, follow these guidelines:
The cord set must consist of a plug, cable and receptacle.
If the unit is rated greater than 12 Amps, use a cord set rated for 20A.
If the unit is rated less than 12 Amps, use a cord set rated for 15A.
The cord set must be approved by local electrical authority or other
acceptable agency.
Ensure the plug is compatible with your local outlets and receptacles.
