Page 37
Assembly
EN
Unpack all contents and check that all parts are present before starting assembly. Please refer to the parts
list.
1. Insert support bar (E) into left side frame (C) and secure with 2 screws (F).
Use the allen key (G) to tighten screws in clockwise direction.
Repeat process with the right side frame stand.
Warning! Ensure feet are fully extended before using crib. NEVER use crib in "crib mode" with the
feet partially or totally retracted.
2
.
Insert the left side frame stand through the casing cloth located on the side of the crib body (A).
Attach the handrail joint to the top of the frame stand tubing as illustrated.
The spring stud will ‘click’ into place once secure. Repeat for the right side frame.
3.
Insert mattress (B) into the crib body.
WARNING! Do not use more than one mattress in the crib.
4. Open the zipper located underneath the padded top rail.
Lift up the side of crib and attach the tubing to the tubing of the crib main body to close the side panel.
Attach the studs on the tubing to secure. Close the zipper to cover the joint.
5. Fasten the crib side using the side zips. The crib is now ready to be used as a standalone crib.
WARNING! Always make sure that the side rail is raised and the zippers are completely closed in
“crib mode”.
Wheels
The crib has wheels located on the front of the frame feet for easy manoeuvring.
Hold the crib near long handrail and lift up to access the wheels. At the same time push the crib forward
or backwards to desired space.
NOTE. There is an anti-slipper at the bottom of the feet to stop the crib moving.
Feet Adjustment
The feet at the base of the crib can be adjusted for storage and transportation.
Press button down as illustrated and pull feet out to adjust the feet length.
WARNING! Ensure the spring pin has clicked into position before placing baby in crib.
WARNING! Ensure feet are fully adjusted before using crib. NEVER use crib in “crib mode” with the
feet partially or totally retracted.
