50 • Control Network Element Manager User’s Manual Nimbra OneSerie
©2006 Net Insight AB, All rights reserved
client-to-server communication is only used for signaling and broadcasting,
512 kbps is sufficient on these channels as well.
The recommendations in this document are for an in-band management
network that is used exclusively for management of the Nimbra nodes. No
consideration has been taken for allowing other traffic.
To limit the load on the DLE server, there is a recommended maximum of
DLE clients in one segment per server.
To limit the load on the gateway, there is recommended maximum number of
nodes that shall have its traffic routed through the gateway.
For availability reasons, when a single DLE server is used, it is recommended
that the gateway for a DLE segment is located on the same node as the DLE
server.
Nimbra One Nimbra 300 Nimbra 290/291
Maximum
recommended
number of DLE
clients for one DLE
server
16 16 16
When working as
gateway: maximum
recommended
number of nodes to
route traffic for
255 255 255
Maximum
recommended
number of DLE
clients on a gateway
3 3 2
Table 1. Configuration recommendations of the DLE in-band network used for
managing the nodes from external management stations
Nimbra One/300 Nimbra 290/291
Client-to-client
channel capacity.
512 kbps (1 slot) 512 kbps (1 slot)
Cannot be configured.
Client-to-server
channel capacity.
512 kbps (1 slot) 512 kbps (1 slot)
Cannot be configured.
Server-to-client
channel capacity.
512 kbps (1 slot) 512 kbps (1 slot)
Cannot be configured.
Server-to-server
channel capacity.
512 kbps (1 slot) Not supported
Time out before
tearing down unused
channels
Default is infinite,
but can be
configured
Default is infinite, but
can be configured
Table 2. Communication specifications of the DLE in-band network
Building networks with DLE
When building in-band management networks using DLE, use the
recommendations listed in Table 1 and Table 2.
