RadioNet
INSTALLATION MANUAL
Page: 4 of 7 pages Revision: 01 Doc. Name: RadioNet - User Manual
Crop Management Technologies
Specifications for RS485 Communication Cable between the RadioNet Host and
GaliNet Controller (Galileo)
Connection to GaliNet W Controller
Host RS 485 RJ11 Plug
A Pin #3
B Pin #4
GaliNet W – Galileo W Controller
CPU Main Card
Communication cable between
the Host and the GaliNet –
GaliNet – Galileo RS485 port.
To Next Page
