3. Connect each node to IOM A in the stack.
◦ Controller 1 port 0b to IOM A port 3 on last drive shelf in the stack.
◦ Controller 2 port 0a to IOM A port 1 on the first drive shelf in the stack.
mini-SAS HD to mini-SAS HD cables
4. Connect each node to IOM B in the stack
◦ Controller 1 port 0a to IOM B port 1 on first drive shelf in the stack.
◦ Controller 2 port 0b to IOM B port 3 on the last drive shelf in the stack.
mini-SAS HD to
mini-SAS HD cables
If you have more than one drive shelf stack, see Installing and cabling for your drive shelf type.
Step 5: Complete system setup
You can complete the system setup and configuration using cluster discovery with only a
connection to the switch and laptop, or by connecting directly to a controller in the system
and then connecting to the management switch.
10
