As you insert the connector, you should feel it click into place; if you do not feel it click,
remove it, turn it around and try again.
About this task
Perform the following step on each controller module.
Steps
1. Cable ports e4a through e4d to the 10GbE host network switches.
Option 3: Cable controllers to single drive shelf
Cable each controller to the NSM modules on the NS224 drive shelf.
Before you begin
Be sure to check the illustration arrow for the proper cable connector pull-tab orientation.
As you insert the connector, you should feel it click into place; if you do not feel it click,
remove it, turn it around and try again.
About this task
Use the animation or the tabulated steps to complete the cabling between the controllers and the single
shelf. Perform the steps on each controller module.
Animation - Cable the controllers to a single NS224
Steps
1. Cable controller A to the shelf.
234
