4. Place the bezel on the front of the system.
Step 3: Cable controllers to network
You cable the controllers to your network by using either the two-node switchless cluster method or the
switched cluster method.
About this task
The following table identifies the cable type with the call out number and cable color in the illustrations for both
two-node switchless cluster network cabling and switched cluster network cabling.
Cabling Connection type
Cluster interconnect
Controllers to host data network switches
Controllers to management network switch
4
To Next Page
