NetApp AFF A150 - Page 345

Locking tabs
Slide air duct toward back of controller
Rotate air duct up
a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module.
b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely
open position.
2. Locate and remove the boot media from the controller module:
343
