Cam handle release button
Cam handle
3. Rotate the cam handle so that it completely disengages the controller module from the chassis, and then
slide the controller module out of the chassis.
Make sure that you support the bottom of the controller module as you slide it out of the chassis.
4. Set the controller module aside in a safe place, and repeat these steps if you have another controller
module in the chassis.
Step 4: Remove the I/O modules
Steps
To remove I/O modules from the old chassis, including the NVRAM modules, follow the specific sequence of
steps. You do not have to remove the FlashCache module from the NVRAM module when moving it to a new
chassis.
