NetComm Wireless NP511 User Manual

6
NP511 – 500Mbps Powerline Adapters User Guide
www.netcommwireless.com
v1.1
Interfaces
#
LABEL
DESCRIPTION/FUNCTION
1
Reset button
Use a paperclip to press this button for no more than 3 seconds to reset the unit to the factory default settings
2
Security button
Press the security button for 10 seconds to reset the private network password. Press the security button for no more
than 3 seconds to begin pairing.
3
Ethernet port
Accepts either crossover or straight-through Ethernet cable.
LED indicators
#
LABEL
STATUS
DESCRIPTION/FUNCTION
4
Power
Off
No power.
On

When Security button is pressed for 10 seconds, this LED will turn OFF and turn ON once to confirm
the private network name reset.

When Security button is pressed for no more than 3 seconds, this LED will blink to confirm the
button press.

Blinks slowly when the adapter is in power saving mode.
5
Ethernet Activity
Off
An Ethernet device is not connected.
On

When the Security button is pressed for 10 seconds, this LED will turn OFF to confirm the private
network name reset.

This LED remains steady when the device is part of a Powerline adapter network.

The LED colours represent the connection rate within the Powerline adapter network whether it is
good (red), better (amber), or best (green).
6
Powerline activity
Off
Device is not connected to a Powerline adapter network.
On

When Security button is pressed for 10 seconds, this LED will turn OFF to confirm the private
network name reset.

This LED remains steady when the device is part of a Powerline adapter network.

The LED colours represent the connection rate within the Powerline adapter network whether it is
good (red), better (amber), or best (green).
