NETGEAR Nighthawk X6 R8000 Quick Start

1
LEDs
The LEDs on the top of the router light to indicate router activity.
You can use the LED On/O switch on the rear panel of the router
to turn the LEDs on the top of the router on or o.
Note: The Power LED stays lit even if the LED On/O switch is in the O
position.
LED On/O switch
Power LED
Internet LED
2.4 GHz WiFi LED
5 GHz WiFi 1 LED
5 GHz WiFi 2 LED
USB 3.0 port LED
USB 2.0 port LED
Ethernet ports 1–4 LEDs
WiFi On/O button and LED
WPS button and LED

NETGEAR Nighthawk X6 R8000 Specifications

General

WiFi Speed	AC3200 (600 + 1300 + 1300 Mbps)
Memory	128 MB Flash and 256 MB RAM
Beamforming	Yes
Dynamic QoS	Yes
Smart Connect	Yes
VPN Support	Yes
Guest Network Access	Yes
Parental Controls	Yes
WiFi Technology	802.11ac
Processor	Dual Core 1GHz
Antennas	6 external antennas
Ports	1 USB 3.0, 1 USB 2.0
