Router Setup Manual
1-6 Connecting the Router to the Internet
v1.0, 2006-03-17
f. Securely insert the Ethernet cable from your modem into the Internet port of the router (3).
g. Securely insert the blue cable (4) that came with your router into a LAN port on the router
such as LAN port 1 (5), and the other end into the Ethernet port of your computer (6).
Your network cables are connected and you are ready to start your network.
2. Start your network in the correct sequence
a. First, plug in and turn on the cable or DSL modem. Wait 2 minutes.
b. Now, plug the power cord into your router and into a power outlet. Wait 1 minute.
Figure 1-4
Figure 1-5
Warning: Failure to start or restart your network in the correct sequence could
prevent you from accessing the Internet.
3
4
5
6
