13
Multi rotation lock, for all types of handwheel and gear
operated valves.
Legend
1. CS powder coated hand wheel / optional AISI 316
2. AISI 316 body
3. Original nut will be used if possible
4. AISI 316 Adaptor - purpose machined - with 4 keyways
5. Easy to set and reset counters behind counter cover plate
6. Linear key
7. Key slots protected with self sealing weather strips
8. Mounting plate to connect bracket to interlock
9. AISI 316 bracket - purpose machined
Basic principles
