17
Legend
1. Handwheel
2. Tube
3. Lock body
4. Adjustment cover
5. Tamper proof M6 screw
6. Operating key
Basic principles
Dimensions MRL-S (small type)
Length (mm) 133
Width (mm) 115
Height (mm) 82
Mass of lock (kg)* 3
Handwheel sizes Dierent sizes between 200 and 700
Max. valve spindle diameter (mm) 26
* Without bracket, adaptor and hand wheel
Dimensions MRL-L (Large type)
Length (mm) 152
Width (mm) 144
Height (mm) 100
Mass of lock (kg)* 4.7
Handwheel sizes Dierent sizes between 380 and 700
Max. valve spindle diameter (mm) 68
* Without bracket, adaptor and hand wheel
