5/8 Port Fast Ethernet Switch User Manual
7
2. Installation
2.1. Before Installation
Take note of the following conditions before using your switch:
¾ Install the 5/8 port Fast Ethernet switch in a fairly cool and dry place. See
Working Environment for
the acceptable operating temperature and humidity ranges
¾ Install the switch in a site free from strong electromagnetic sources, vibration, dust, and direct
sunlight.
¾ Leave at least 10cm of space to both the left and right of the switch for ventilation.
¾ Visually inspect the DC power jack and make sure the power adapter cord is securely connected.
¾ Do not place items on top of switch
2.2. Connecting the 5/8 Port Fast Ethernet Switch to Your
Network
Description Function
PWR
Connect to power adapter provided with unit. Don’t use other
power adapters as your switch could be damaged.
LAN1-5/8
These ports support network speeds of 10Mbps or 100Mbps, and
can operate in half and full-duplex transfer modes. These ports also
support automatic MDI/MDIX detection, which gives the Switch
true ‘plug and play’ capabilities. Just connect any network cable
from a device to the switch, and the switch will automatically
detect the settings of the device and adjust itself accordingly.
2.3. LED Indicators
The LED Indicators will allow you to monitor, diagnose and troubleshoot any potential problem with the
switch, connection or attached devices.
LED Function
PWR
On Power on
Of
