Interface description
A quad band antenna (GSM 850/900/1800/
1900) can be connected to the RF
interface.
The connection is implemented as a 50 Ω
SMA coaxial jack.
Antenna connector
Antenna connector
SMA
Signal name PIN I/O Description
RF Inner I/O RF input/output
GND Outer X Frame connection
Purpose of the connectors/connections
