Page 10
NetworX NX Series Receiver Modules
5) Enter [4] [9] [#] to enter the sensor learning location.
The Ready LED should turn on and the Armed LED
should turn off.
6) Enter [XX] [✻], where [XX] is a zone number (1
through 48) and [✻] is the entry key.
Note: Three beeps from the keypad indicates an entry
error. This occurs if you enter a transmitter num-
ber that is not within the module’s zone block or if
you try learning a sensor that is already learned
into the module.
If you change your mind about your entry, you
can terminate programming by entering [4] [9] [#]
[0] [
✻]. Then, start again from step 5.
7) Trip the desired transmitter (within 250 seconds) as
described in Table 5. Listen for the ‘ding dong’ for
confirmation.
8) Program remaining transmitters by repeating steps 5-7.
9) Exit program mode by entering [EXIT] [EXIT].
Program Transmitter and Partition
Settings
This section describes programming guidelines, how to
change the supervision windows, and program the transmit-
ter and partition settings using the information you entered
in the Table 3 programming worksheets.
Changing the Transmitter Supervision
Windows
Note: For UL Listed installations, the normal supervi-
sion window must be set to 24 hours and the fire
supervision window must be set to 4 hours.
CAUTION: Do not set the normal or fire supervision win-
dows to 1 hour. This causes false trouble
reports from all learned wireless transmitters.
1) Enter [✻] [8] at the keypad. The five function lights
should start flashing.
2) Enter the “Go To Program Code” (factory default is 9 7
1 3). The service light should flash and the five func-
tion lights should change from flashing to on steady.
3) Enter [XX] [#], where [XX] is the DIP switch setting
module number and [#] is the entry key. The Armed
LED should turn on, indicating the control panel is
waiting for a programming location entry.
4) Enter [0] [#] to enter location 0, segment 1.
5) Enter the new normal supervision time (0 - 255).
Note: Choosing 0 sets the normal supervision window
to 256 hours.
6) Press [✻] to save any changes and automatically enter
segment 2.
7) Enter the new fire supervision time (0 - 255).
Note: Choosing 0 sets the fire supervision window to
256 hours.
Table 5. Tripping Transmitters for Learning
Transmitter Action
Door/Window, Shock,
Glass Guard, Freeze
Activate tamper switch by
removing cover.
Door/Window with Exter-
nal Contact
Activate tamper switch by
removing cover. (Note:
Feature 3—Input Option
1, must be on.)
Recessed Door/Window Activate tamper switch by
removing circuit board
until tamper switch is
exposed.
Micro Door/Window Slide the battery about
half-way out of the battery
holder, then back.
PIR Activate tamper switch by
removing back plate from
PIR.
Smoke Detector Press and hold the test but-
ton.
Heat Detector Press, then release the
tamper switch.
Fire Pull Activate tamper switch by
removing sensor cover.
Single Button Panic Press and hold the button.
Dual Button Panic Press and hold both but-
tons together.
Keyfobs Press and hold the arm and
disarm buttons together.
Repeater Press, then release the
tamper switch.
Table 5. Tripping Transmitters for Learning
Transmitter Action
