NetworX NX-448 User Manual

Page 4
NetworX NX Series Receiver Modules
Table 3. Module Programming Worksheet Table
Location Segment 1 Segment 2
0 (Supervi-
sion)
1 - Normal ______hrs.
(0 - 255 hours;
default = 24 hours)
Fire ______hrs.
(0 - 255 hours;
default = 4 hours)
1 (Zone 1)
Assigned to
module
#_____.
1 - Enable sensor ❏
(default = off)
2 - Supervised ❏
(default = on)
3 - Input option 1 ❏
(default = off)
4 - Input option 2 ❏
(default = off)
5 - Xmitter not lost* ❏
(default = off)
6 - Low battery* ❏
(default = off)
7 - Last signal good* ❏
(default = off)
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
(default = on)
Partition 2 keyfob ❏
(default = off)
Partition 3 keyfob ❏
(default = off)
Partition 4 keyfob ❏
(default = off)
Partition 5 keyfob ❏
(default = off)
Partition 6 keyfob ❏
(default = off)
Partition 7 keyfob ❏
(default = off)
Partition 8 keyfob ❏
(default = off)
2 (Zone 2)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
3 (Zone 3)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
4 (Zone 4)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
5 (Zone 5)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
6 (Zone 6)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
7 (Zone 7)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
8 (Zone 8)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
9 (Zone 9)
Assigned to
module
#_____.
1 - Enable sensor ❏
2 - Supervised ❏
3 - Input option 1 ❏
4 - Input option 2 ❏
5 - Xmitter not lost* ❏
6 - Low battery* ❏
7 - Last signal good* ❏
8 - Not used*
(*Read only location)
Partition 1 keyfob ❏
Partition 2 keyfob ❏
Partition 3 keyfob ❏
Partition 4 keyfob ❏
Partition 5 keyfob ❏
Partition 6 keyfob ❏
Partition 7 keyfob ❏
Partition 8 keyfob ❏
Table 3. Module Programming Worksheet Table
(cont.)
Location Segment 1 Segment 2
