NEU MASTER N3020 - Setup; Material Preparation; Aligning the Suction Tube; Fill Container

Setup
1.TurnbothknobsonbothsidesoftheAirCompressorAssemblytothe
“Unlock”position,andInsertthespraygunintotheAirCompressor
Assemblyintoplace,
2.TurnbothknobsonbothsidesoftheAirCompressorAssemblytothe
“Lock”positiontolockthetwopiecesintoplace.












AligningtheSuctionTube
Ifyouaregoingtobesprayinginadownwarddirection,
theangledendofthesuctiontubeshouldbepointing
towardthefrontofthegun.










Ifyouaregoingtobesprayinginanupwarddirection,
theangledendofthesuctiontubeshouldbepointing
towardtherearofthegun.





Bypointingthesuctiontubeintheproperdirection,you
willnothavetorefillthecontainerasoften..
MaterialPreparation
Beforespraying,thematerialbeingusedmayneedtobe
thinnedwiththepropersolventasspecifiedbythe
materialmanufacturer.Neverexceedthethinning
advicegivenbythecoatingmanufacturer.
Donotusematerialswithaflashpointbelow70°F
(21°C).Followtheinstructionsbelow.
1.Stirthesprayingmaterialthoroughlybeforemeasuring
viscosity.
2.Diptheviscositytestcupcompletelyintothespraying
material.





3.Holdthetestcupupandmeasurethetimeinsecondsuntil
theliquidemptiesout.Thistimeisreferredtobelowas
RunoutTime.

ThinningChart
MaterialRunoutTime 
1)Oilenamel25‐40
2)Oilbasedprimer30‐45
3)OilstainNothinningrequired
4)ClearsealerNothinningrequired
5)PolyurethaneNothinningrequired
6)Varnish20‐50
Materialtobesprayedshouldalwaysbestrainedtoremoveany
impuritiesinthepaintwhichmayenterandclogthesystem.Impuritiesin
thepaintwillgivepoorperformanceandapoorfinish.
MATERIALFLASHPOINTMUSTBE70°F(21°C)OR
HIGHER.
FillContainer
1.Unscrewthecupfromthespraygun.
2.Afterthematerialhasbeenproperlythinnedandstrained,
fillthecontainertothetopoftheneck.





3.Carefullyscrewthecupbackontothespraygun.

