Cleanup
CleaningtheSprayGun
Specialcleanupinstructionsforusewith
flammablesolvents(musthaveaflashpointabove
70ºF(21ºC):
•Alwaysflushspraygunoutside.
•Areamustbefreeofflammablevapors.
•Cleaningareamustbewell‐ventilated.
•DONOTSUBMERGEAirCompressor!
1.Unplugthespraygun,
and
triggerthespraygunsothat
thematerialinsidethespray
gunflowsbackintothe
container.
2.Unscrewthecontainer.
Emptyanyremainingmaterial
backintothematerial
container.
3.Pourasmallamountofthe
appropriatecleaningsolution
intothecup(warm,soapy
waterforlatexmaterials;
mineralspiritsforoil‐based
materials).Cleancupand
properlydisposeof
cleaningsolution.
4.RefillthecupwithNEW
cleaningsolution.
5.Attachthecuptothegunand
pluginthesprayer.
6.Spraythesolutionthroughthe
gunfortwosecondsinasafe
area.Sprayagainfortwo
seconds.Unplugthespray
gun,andtriggerthespraygun
sothatthematerialinsidethe
spraygunflowsbackintothe
container.
7.Wipetheexteriorofthe
cup
andgununtilclean.
8.Unscrewthenutand
removetheaircap
andnozzle.
9.Cleanthecontainer,
suctiontube,aircap
andnozzlewitha
cleaningbrushand
theappropriate
cleaningsolution.
Nevercleannozzleorairholesinthespraygunwith
sharpmetalobjects.Donotusesolventsorlubricants
containingsilicone.
10.Turnbothknobsonbothsides
oftheAirCompressorAssembly
tothe“Unlock”position,pulland
separatethespraygunfromthe
AirCompressorAssembly.
11.(a)Cleantherearofthespray
gunwiththeappropriatecleaning
solution.
(b)Turnthesuction
tube
anti‐clockwiseandpullthesuction
tubedownwardtodisassembleit
fromthespraygun.Thencleanthe
suctiontubewiththeappropriate
cleaningsolution.
Attention! TheSealRing(4)betweenSuctionTube1(3)andSuctionTube
2(5)mustbeputbackintoplaceaftercleaning.Otherwise,somepaintin
thecontainerwillbesuckedintotheairductandinterferewiththe
functionoftheunit.
6
(a)
(b)
