! Position the template onto the
reverse of the furniture door. It
is possible to mount the hinges
and closure magnet on the right
or left-hand side depending on
your requirements. Mark the
screw hole positions, then drill
out these positions.
! Fix the hinges in place with the
4 screws provided (A).
! Fix the magnet (B) in place
using screw (C).
! Mount the plate (D) on the right
or left-hand side, depending on
your installation requirements.
Place the plastic support (E)
under the plate and fix it in
position with screw (F).
! Snap mount cap (G) in the
lower position.
