SPECIFICATIONS
Electrical
Nominal input level -10 dBV, instrument level
Absolute max input level 6 dBV
Input impedance 1 MΩ (mono), 2 MΩ (stereo)
Output impedance 500 Ω (mono), 1 kΩ (stereo)
Gain, enabled vs. bypass 0 dB (mix @ 0)
Frequency response 20 Hz—20 kHz, +0.1 dB, -0.5 dB
(dry signal or bypassed)
Total harmonic distortion < 0.003 % typical (dry signal or bypassed,
22 Hz—22 kHz, 1.0 Vrms, 1 kHz)
Signal-to-noise ratio 112 dB mono, 110 dB stereo (A-weighted)
Power
Power adapter input 9-12 V DC, 70 mA
Plug: center-negative, 5.5 mm OD x 2.1 mm ID
Physical
Dimensions 2.9” W, 4.6” L, 2.0” H / 73 mm W, 117 mm L, 51 mm H
Weight 8.5 oz / 240 g
*Specifications subject to change without notice.
