4.2 Excavator components
1 2
4
5
6
7
8
9
10
11
3 13 12
Excavator components 12002 RD
1 Main hydraulic valve unit
2 Hydraulic-oil level indicator
3 Location of fire extinguisher within
toolbox
4 Oil drain
5 Diesel drain
6 Opening for filling hydraulic oil
7 Tank supports
9707672_user manual_en
8 Diesel tank
9 Return filter
10 Diesel pump (Optional)
11 Battery
12 Oil tank
13 Engine cover
