User manual
5
5.1
Safety Equipment
Parking Brake and Locking Mechanism
The brakes and parking brake as well as the locking
mechanism
are automatically activated when the excavator is at a
complete
stop (no pilot control pressure).
The brakes and locking mechanism only release when a
drive or
control lever is activated (pressure builds up).
5.2 Seat
CAUTION: The steering control console MUST be folded back
when getting into or out of the crawler excavator in
order to block the function of the hydraulic system.
ATTENTION: Console down = Work and hydraulic
functions
operational
Console up = Work and hydraulic functions
interrupted
Console down
Work functions
operational
Console up
Work functions
interrupted
9707672_user manual_en
- 33 -
