Option
28.7 NEUSON VARIO
Operation of Neuson Vario
To change the eccentric position, the following steps must
be
absolutely observed.
1. The dipper stick must be supported on the
ground.
2. To open the lock of Neuson Vario both front switches
at the
left and the right joystick must be pushed and kept
pressed.
At Neuson Vario there are four locking positions, each offset
by
90° (0°/360°, 90°, 180°, 270°).
To reach the correct position the left joystick must be
pushed left
or right.
After the excavator has moved the two buttons may be
released.
After turning by 90° Neuson Vario engages automatically.
If the Neuson Vario shall be offset by more than 90°, the
buttons
at the joystick must be kept pressed beyond the 90° offset.
As soon as the buttons are released, the Neuson Vario
engages
at the next possible lock.
9707672_user manual_en
- 82 -
