28.5 Diesel Pump
The diesel pump is situated at the hydraulic oil tank below the
valve
cover.
NOTE:
28.6 Air-Conditioning Unit
Control Elements
Function
The first control element serves for switching on and/or off the
air-
conditioning function. The next one serves for adjusting cold/hot.
The
blower is situated at the third control element. There are three
different
settings for the blower. These settings determine only the
intensity of
blowing .
The grille screen of the air-conditoining unit is situated in the foot
area of
the seat and can be openend manually and closed again, if
required.
NOTE: To achieve an optimum cooling effect, all
windos
and doors must be closed.
Switch off the diesel pump immediately after refuelling
the
excavator, otherwise defects may occur.
WARNING: grille screen closed = air-conditioning function
interrupted
grille screen open = air-conditioning function ready
