Page #40 background image
Parts List - Drivetrain Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
211251 Drivetrain Assembly (includes all items below)
14 210981 Screw, M3.5 x 25 mm, Phillips Pan
20 211041 Nut, Nylon Lock, 1/4"-20
29 210931 Screw, 1/4"-20 x 1", Phillips Pan, SS
35 209831 Frame, Drivetrain
36 209861 Motor/Gearbox Assembly
37 209851 Cover, Drivetrain
38 211181 Cap, Drivetrain Cover
39 211151 PCB Assembly with Wire Harness
40 209781 Spacer, PCB Mount
41 211161 Pad, 1.3" x 1.6" x .12", Harness
42 210991 Screw, M5 x 16 mm, Phillips Pan
43 211011 Washer, Lock, .20" ID x .30" OD x .05", Split
44 211061 Nut, M5 x 6 mm, Hex
45 207311 Battery Door
36 NEUTON
®
GARDEN CART
Safety & Operating Instructions
